35 ton electronic plug vertical injection molding machine

FOB Reference Price:Get Latest Price
$8,000.00 - $9,000.00 / Units | 1 Unit/Units (Min. Order)
Clamping Force:
343(35)kN(tf)
Lead Time:
Quantity(Units) 1 - 5 >5
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Distance between Tie Bars:
370*210mm
Condition:
New
Type:
Preform Injection
Style:
Vertical
Brand Name:
Lichuang
Model Number:
V35
Place of Origin:
Guangdong, China
Plastic Type:
Thermoplastic
Automatic:
Semi-auto
Opening Stroke:
200mm
Certification:
ISO9001
After-sales Service Provided:
Online support
Warranty:
1 year
Screw Diameter:
22/25/28mm
Theoretical Injection volume:
53cm3
Max. Injection Pressure:
248(2530)Mpa(kgf/ cm2 )
Injection Speed:
116(186)mm/s
Screw Rotation Speed:
0~300r.p.m
Nozzle Projecting Template Size:
more than 45mm
Min Mold Height:
150(200)mm
Max Daylight:
350(400)mm
Distance Between Tie Bars:
370*210
Max. Mold Size:
350*340
Injection Weight:
49(1.7)g(oz)
Injection Rate:
116mm/s
Power(W):
5.5KW
Supply Ability
Supply Ability:
50 Unit/Units per Month for 35 ton injection molding machine
Packaging & Delivery
Packaging Details
standard package for exporting
Port
Shenzhen, Guangzhou
Lead Time :
Quantity(Units) 1 - 5 >5
Est. Time(days) 30 To be negotiated

35 ton electronic plug vertical injection molding machine from China



Product Description
Specification for  35 ton electronic plug vertical injection molding machine from China
Model UnitV35
INJECTION UNITScrew Diametermm222528
Theoretical Injection volumecm35368.886
Injection Capacity(PS)g(oz)49(1.7)63.8(2.2)80(2.8)
Injection PressureMpa(kgf/ cm2)248(2530)192(1960)153(1563)
Injection Ratecm3/s445771
Injection Speedmm/s116(186)
Screw Rotation Speedr.p.m0~300
Nozzle Projecting Template Size mmmore than 45
CALMPING UNITClamping Forcetf343(35)
Opening Strokemm200
Min Mold Heightmm150(200)
Max Daylightmm350(400)
Distance Between Tie Barsmm370×210
Max. Mold Sizemm350×340
Slide sizemm500×360
Ejector Strokemm40
Ejector ForcekN(tf)17.2(1.75)
OTHERS System PressureMpa(kgf/ cm2)13.7(140)
Oil Tank CapacityL130
Electric PowerkW(HP)5.5(7.5)
Heater PowerkW3.6
Machine Dimension /L×Wmm1539×1152
Machine Dimension/Hmm2196(2811)
Machine Weightton1.3









Application:

Company Information

Dongguan Lichuang Machinery Co., Ltd. , located in Qiaotou Town, Dongguan City, China, is a modern enterprise with integration of researching, developing, manufacturing and selling. Lichuang specializes in injection molding machine. Since its establishment, the range products has always been enlarged with the development of various plastic products, sophisticated requirements, growing market and upgrading injection molding machine equipment. Our main products include: vertical injection molding machines, horizontal injection molding machines, C-type injection molding machines, vertical single slide injection molding machines, vertical double slide injection molding machines, vertical rotary injection molding machines and so on. Integrity is our purpose and customers’ need is our guideline. We recommend the most suitable injection molding machine according to customers’ requirements to ensure the machine can be put into production immediately. At the time, the injection molding machine can be customized and redesigned by your special requirements.

Main category:

Customer



Packaging & Shipping





FAQ



Q: All of your products are made by your self or compacted via purchasing the others?
A: We have independent technical team who focus on making machines; all the products are made by our technical team.



Q:What about your warranty?

A:Our warranty is 1 years, all machine part can be replaced for free within 1 year if broken(not including man made).



Q: Do you have any other service about your products?
A: We have a lot of experience on making complete “Turn-Key” projects and specifications for our clients. Also we have a fixed service system



Q:Where is your factory? Can I visit your factory?

A:Our factory is located on Dongguan city which near Shenzhen and Guangzhou City. We are warmly welcome you to visit our factory, we can pick you up when you come to Dongguan bus or train station.



How to contact us

Ms Jane Huang
Tel: 0086-0769-83139868                                             Fax:0086-0769-83007177
Mobile: +86-159 9293 2407                                         Wechat: +86-159 9293 2407
WhatsApp: +86-159 9293 2407                                 Skype: Jane Huang 0707
Web: www.lichuangmachinery.com                        Web in Ali: lcamchina.en.alibaba.com

E-mail: janehuang @ lichuangmachinery.com
